T Din 650 200x200 Slotted Angle Plate OEM Design

T Din 650 200x200 Slotted Angle Plate OEM Design
T Din 650 200x200 Slotted Angle Plate OEM Design

Large Image :  T Din 650 200x200 Slotted Angle Plate OEM Design

Product Details:
Place of Origin: China
Brand Name: OEM
Certification: CO, FORM-E
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: wooden
Delivery Time: 20days
Payment Terms: Western Union, T/T
Supply Ability: 10/monthd
Detailed Product Description
Material: Grey Iron HT250 Name: Precision Cast Iron Bed Plate With T-Slot
Type: Hollow Type Flatness: 3 Grade
Surface Finish: Hand Scrap Loading Weight: As Clients Request
Casting Method: Sand Casting Surface Treatment: Spray-Paint
Coating: Alcohol, Graphite
High Light:

slotted angle plate oem


200x200 slotted angle plate


din 650 slotted angle plate

Precision Cast Iron Bed Plate with T-Slot


All the size or design can be made according to your requirement or drawings.
Flatness accuracy standard: DIN876
T-slots are made as per DIN650.
Stand or leveling jacks,leveling bolts are available.
Standard size are in stock.
Testing report or certificate can be offered.
Painting colour can be request.

These plates are available in a wide range of sizes up to 3m wide and 10m long in a one-piece design.Unlimited size when used in combination.Othe thickness can also be provided on speical order.


Professional nitriding processing technology research and development, independent innovation.Professional design.

Good cooperation:

Our members have many years of technical experience and are equipped with advanced and first-rate production equipment.Perfect products.Let the customer with ease, rest assured.

Bloom grow:

The company is an "international, professional, high-level" casting manufacturer


Standard: GB/T22095-2008
Specification: 200x200-3000x8000mm or customize
Surface: flat (accessories are available according to your requirement, like V, T, straight-shaped slots and tapped holes, long
holes, grid lines, etc)
Hardness of the working surface: HB160-240
Surface treatment: hand-scraped, finish-milling or ground finish
Foundry process: sand casting or centrifugal casting
Molding type: resin sand molding
Painting: primer and face paint
Surface coating: pickling oil and plastic-lined or covered with anticorrosion paint
Surface flatness: Master, Working, Reference
Precision grade: 0-3
Working temperature: (20±5)℃
Packaging: plywood box

Precision: According to the national standards measurement examination regulations execution,

respectively is 1,2,3, fine polish.

Specification (mm) Flatness tolerance (um)
  Grade1 Grade2 Grade 3 Finihs plane
400x400 12 24
600x400 14 28
800x500 16 32 80
900x600 16 32 80
1000x750 18 36 90
1000x1000 20 39 96
1500x1000 25 48 120
2000x1000 26 52 129
2000x1500   56 140
2000x2000   60 152 230
2500x1500   68 168 248
3000x1000     174 248
3000x2000     184 275
3000x3000     210 300
4000x1000     210 300
4000x2000     219 310
4000x3000     240 360
5000x2000     255 375
5000x3000     287 420
6000x2000     293 430
6000x3000     308 460
8000x2000     370 520
8000x3000     382 570



We manufacture and supply a wide range of Cast iron inspection surface plate, which are used in various industries for tool making, inspection, spotting, gauging etc. Our range of surface plates are specifically designed to provide an accurate reference plane for work inspection and also for work layout. Our cast iron surface plates are strictly in compliance with international quality standards and can also be customized as per the specifications laid down by our clients.


T Din 650 200x200 Slotted Angle Plate OEM Design 0
